Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
- 96 - HD09-S Series User Manual V1.1
Ref. Code Function Setting Range Default Unit
Attribute
Setting
F15: Digital Input / Output Terminals Parameter
F15.00 DI1 function
0: Reserved
1: Inverter enable
2,3: FWD / REV enable
4: Three-wire system operation control
8: Frequency switched to the simulation
11: Command switching terminals
13 - 15: Multistage frequency terminals
1 - 3
17,18: Increasing (UP) / decreasing
frequency (DN) instructions
20,21: FWD / REV point move command
control input (JOGF / JOGR)
26,27: Acc. / Dec. time choose terminals
1, 2
30: Switch to normal running mode
41,42: Free down normally open /
closed input
43: Emergency stop
44,45: The external input fault normally
open / closed
46: External reset input
50: Counter reset signal input
51: Counter trigger signal input
53: Pulse frequency input (DI4)
86: Terminal stop DC brake
2 1
×
F15.01 DI2 function 3 1
×
F15.02 DI3 function 0 1
×
F15.03 DI4 function 0 1
×
F15.44 AI terminal (ADI) function 0 1
×
F15.12
Terminal UP / DOWN of the
rate of Acc. and Dec.
0.00 - 99.99Hz/s
1.00
Hz/s
0.01
Hz/s
×
F15.13
Terminal detection interval
time
0: 2ms
1: 4ms
2: 8ms
0 1
○
F15.14
Number of terminal
detection filter
0 - 10000 4 1
○
F15.15
Positive and negative
terminal input logic setting
Bit0 - Bit3 is corresponding to DI1 - DI4
Bi12 is corresponding to AI
Bitx: Diy, AI terminal input positive and
negative logic
0: Positive logic
1: Negetive logic
00 1
○
