Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F15.16
FWD / REV operation mode
setting
0: Two line operation mode 1
1: Two line operation mode 2
2: Three line operation mode 1
3: Three line operation mode 2
0 1
×
F15.19 DO function
0: Reserved
2: The inverter is running (RUN)
3: The inverter is running FWD
4: The inverter is running reversely
5: DC brake
6: Zero-frequency inverter status
7: Zero-frequency inverter operation
9: Frequency level detection signal
(FDT)
11: Frequency arrival (FAR)
12: Max. frequency limit
13: Frequency lower limit
20: Data output by SCI communication
21: Set run time arrive
23: Set the count value arrive
24: Specifies the count value arrive
29: Undervoltage lockout is stopped
30: Overload detection signal
31: Inverter failure
32: External fault
33: Frequency inverter fault
automatically reset period
38: Pulse output (DO only)
2 1
×
F15.20 RLY 1 function 31 1
×
F15.24
Positive and negative
output terminal logic
settings
Bit1 is corresponding to DO
Bit2 is corresponding to RLY1
0: Positive logic
1: Negative logic
0 1
○
F15.27
Frequency reach (FAR)
width detection
0.00 - 100.00Hz 2.50Hz 0.01Hz
○
F15.28
Zero-frequency signal
detection value
0.00Hz - F00.08 0.00Hz 0.01Hz
○
F15.29 Zero frequency 0.00Hz - F00.08 0.00Hz 0.01Hz
○
F15.31 FDT electrical level 0.00Hz - F00.08 5.00Hz 0.01Hz
○
F15.32 FDT delay 0.00Hz - F00.08 0.00Hz 0.01Hz
○
