hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09-S Series User Manual V1.1 - 99 -
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F16.26
DO terminal output max.
pulse frequency
0.01 - 50.00kHz
10.00
kHz
0.01
kHz
○
F17: SCI Communication Parameter
F17.00 Data format
0: 1-8-2 format, no parity, RTU
1: 1-8-1 format, even parity, RTU
2: 1-8-1 format, odd parity, RTU
6: 1-8-1 format, no parity, RTU
0 1
×
F17.01 Baud rate choice
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
5: 38400bps
6: 57600bps
7: 76800bps
8: 115200bps
3 1
×
F17.02 The machine address 0 - 247 2 1
×
F17.03
This machine response
time
0 - 1000ms 1ms 1ms
×
F
timeout
LAN communication
timeout detection time
0.0 - 600.0s 0.0s 0.1s
×
F17.05
Communication error
detection time
0.0 - 600.0s 0.0s 0.1s
×
F17.06
Communication overtime
action choice
0: Freewheel stop
1: Emergency stop
2: Dec. stop
3: Continue to run
3 1
×
F17.07
Communication error
action selection
3 1
×
F17.08
Communication external
device fault action
selection
1 1
×
F17.09
Communication write
function parameter saving
EEPROM choice
Unit: Except of F00.13, F19.03 function
parameter, communication EEPROM
storage options
Ten: F00.13, F19.03 function parameter
communication EEPROM storage
options
0: Not save
1: Save
01 1
×
