hpmont HD09-S Series User Manual

Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
- 100 - HD09-S Series User Manual V1.1
Ref. Code Function Setting Range Default Unit
Attribute
Setting
F17.10
Network communication
timeout detection time
0.0 - 600.0s 0.0s 0.1s
×
F18: Display Control Parameter
F18.02
Running display parameter
1 setting
0: Reserved
1: Inverter rated current
3: Inverter status
4: Main set frequency channel
5: Main set frequency
7: Set frequency
8: Setting frequency (after Acc. and
Dec.)
9: Output frequency
10: Set the speed
11: Running rpm
13: Output voltage
14: Output current
15: Torque reference
16: Output torque
17: Output power
18: DC bus voltage
19: Keypad potentiometer input
voltage
20: AI input voltage
21: AI input voltage (after processing)
28: DI4 terminal pulse input frequency
29: AO output
32: Radiator temperature
33: Set the line speed
34: Setting line speed
42: External count value
43: Input terminal status
44: Output terminal status
48: Power-on time accumulated (hours)
49: Run time accumulated (hours)
8 1
○
F18.03
Running display parameter
2 setting
7 1
○
F18.04
Running display parameter
9 setting
9 1
○
F18.05
Running display parameter
4 setting
13 1
○
F18.06
Running display parameter
5 setting
14 1
○
F18.07
Running display parameter
6 setting
18 1
○
F18.08
Stopping display
parameter 1 setting
7 1
○
F18.09
Stopping display
parameter 2 setting
18 1
○
F18.10
Stopping display
parameter 3 setting
20 1
○
F18.11
Stopping display
parameter 4 setting
19 1
○
F18.12
Stopping display
parameter 5 setting
43 1
○
F18.13
Stopping display
parameter 6 setting
44 1
○
F18.15 Max. line velocity 0 - 65535 1000 1
○
F18.16
Line speed display
accuracy
0: Interger
1: A decimal
2: Two decimal places
3: Three decimal places
0 1
○
