hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09-S Series User Manual V1.1 - 89 -
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
2/3: Cope the storaged parameter 1/2
of keypad to controller board for
current function code value updating
4: Clear out fault records
5/6: Keypad storage parameters 1/2 is
copied to the control keypad and
update the current function code
setting (including motor parameters)
F01.03
Copy the parameters to
keypad
0: No action
1/2: Current function code value is
copied to keypad storage parameter
1/2
0 1
×
F02: Start and Stop Controlling Parameter
F02.00 Start mode selection
0: Start from starting DWELL frequency
1: Brake firstly and then start from
DWELL frequency
1 1
×
F02.01 Starting delay time 0.00 - 10.00s 0.00s 0.01s
×
F02.02
Frequency setting of
DWELL starting
0.00Hz - F00.08 0.00Hz 0.01Hz
×
F02.03
Frequency keeping time of
DWELL starting
0.00 - 10.00s 0.00s 0.01s
×
F02.04 DC brake current setting 0 - 100% (inverter rated current) 50% 1%
×
F02.05 Starting DC braking time 0.00 - 60.00s 0.00s 0.01s
×
F02.13 Stoping mode selection
0: Reserved
1: Stop freely
2: Dec. stop + DC brake
2 1
×
F02.14
DWELL frequency setting
in stopping
0.00Hz - F00.08 0.00Hz 0.01Hz
×
F02.15
DWELL frequency keeping
time in stopping
0.00 - 10.00s 0.00s 0.01s
×
F02.16
Starting frequency of
stopping DC braking
0.00 - 50.00Hz 0.50Hz 0.01Hz
×
F02.17
DC braking waiting time at
stop
0.00 - 10.00s 0.00s 0.01s
×
F02.18 Stopping DC braking time 0.00 - 60.00s 0.00s 0.01s
×
F02.19 Jog control mode
0: The jog functions of start and stop
mode etc are invalid
1: The jog functions of start and stop
mode etc are enabled
0 1
×
