hpmont HD09-S Series User Manual

Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
- 90 - HD09-S Series User Manual V1.1
Ref. Code Function Setting Range Default Unit
Attribute
Setting
F02.20 Pre-excitation time 0.00 - 0.50s 0.01s 0.01s
×
F03: Acc. and Dec. Parameter
F03.00 Acc. / Dec. mode selection
0: Linear Acc. / Dec.
1: S curve Acc. and Dec.
0 1
○
F03.01 Acc.time 1 0.1 - 6000.0s 10.0s 0.1s
○
F03.02 Dec.time 1 0.1 - 6000.0s 10.0s 0.1s
○
F03.03 Acc.time 2 0.1 - 6000.0s 10.0s 0.1s
○
F03.04 Dec.time 2 0.1 - 6000.0s 10.0s 0.1s
○
F03.05 Acc.time 3 0.1 - 6000.0s 10.0s 0.1s
○
F03.06 Dec.time 3 0.1 - 6000.0s 10.0s 0.1s
○
F03.07 Acc.time 4 0.1 - 6000.0s 10.0s 0.1s
○
F03.08 Dec.time 4 0.1 - 6000.0s 10.0s 0.1s
○
F03.09
Frequency switchover of
Acc. time 2 and 1
0.00Hz - F00.08 0.00Hz 0.01Hz
×
F03.10
Frequency switchover of
Acc. time 2 and 1
0.00Hz - F00.08 0.00Hz 0.01Hz
×
F03.11
S-curve characteristic time
at starting Acc.
0.00 - 2.50s 0.20s 0.01s
○
F03.12
S-curve characteristic time
at ending Acc.
0.00 - 2.50s 0.20s 0.01s
○
F03.13
S-curve characteristic time
at starting Dec.
0.00 - 2.50s 0.20s 0.01s
○
F03.14
S-curve characteristic time
at ending Dec.
0.00 - 2.50s 0.20s 0.01s
○
F03.15 Inching Acc. time 0.1 - 6000.0s 6.0s 0.1s
○
F03.16 Inching Dec. time 0.1 - 6000.0s 6.0s 0.1s
○
F03.17
Dec. time of emergency
stop
0.1 - 6000.0s 10.0s 0.1s
○
F04: Process PID Controlling Parameter
F04.00
Process PID function
selection
0: PID control invalid
1: PID control valid
0 1
×
F04.01 Setting channel selection
0: Digit setting
1: Analog setting
2: Terminal pulse setting
3: AI1 terminal is setting
7: Keypad potentiometer is setting
0 1
×
