hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09-S Series User Manual V1.1 - 91 -
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F04.02 Feedback access selection
0: Analogue feedback
1: Terminal impulse feedback
0 1
×
F04.03 Setting para. digital setting -100.0 - 100.0% 0.0% 0.1%
○
F04.04 Proportional gain (P) 0.00 - 10.00 2.00 0.01
○
F04.05 Integral time (I) 0.01 - 10.00s 1.00s 0.01s
○
F04.06 Points limit 0.00Hz - F00.08 50.00Hz 0.01Hz
○
F04.07 Derivative time (D) 0.00 - 10.00s 0.00s 0.01s
○
F04.08 Differential limiting values 0.00Hz - F00.08 20.00Hz 0.1Hz
○
F04.09 Sampling period (T) 0.01 - 50.00s 0.10s 0.01s
○
F04.10 Deviation limit 0.0 - 20.0% 0.0% 0.1%
○
F04.13 PID regulator upper limit 0.0 - 100.0% 100.0% 0.1%
×
F04.14 PID regulator lower limit 0.0 - 100.0% 0.0% 0.1%
×
F04.17 PID output filter time 0.01 - 10.00s 0.05s 0.01s
○
F04.18 PID output REV choice
0: PID adjust the inversion is prohibited
1: PID output is allowed to reversal
0 1
×
F04.19
PID output inversion
frequency limit
0.00Hz - F00.08 50.00Hz 0.01Hz
×
F05: External Setting Curve Parameters
F05.00
External setting curve
selection
0: Straight line
1: Reserved
2: Polylines
3: No treatment
3 1
○
F05.01 Line Min. setting 0.0% - F05.03 0.0% 0.1%
○
F05.02
Line Min. setting
corresponding
0.0 - 100.0% 0.0% 0.1%
○
F05.03 Line Max. setting F05.01 - 100.0% 100.0% 0.1%
○
F05.04
Line Max. setting
corresponding
0.0 - 100.0% 100.0% 0.1%
○
F05.09 Max. reference of polyline F05.11 - 100.0% 100.0% 0.1%
○
F05.10
Max. reference
corresponding value of
polyline
0.0 - 100.0% 100.0% 0.1%
○
F05.11
Inflection point 2 reference
of polyline
F05.13 - F05.09 100.0% 0.1%
○
F05.12
Inflection point 2
corresponding value
0.0 - 100.0% 100.0% 0.1%
○
