hpmont HD09-S Series User Manual

Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
- 92 - HD09-S Series User Manual V1.1
Ref. Code Function Setting Range Default Unit
Attribute
Setting
F05.13
Inflection point 1 reference
of polyline
F05.15 - F05.11 0.0% 0.1%
○
F05.14
Inflection point 1
corresponding value
0.0 - 100.0% 0.0% 0.1%
○
F05.15 Min. reference of polyline 0.0% - F05.13 0.0% 0.1%
○
F05.16
Min. reference
corresponding value of
polyline
0.0 - 100.0% 0.0% 0.1%
○
F05.17 Hopping frequency F00.09 - F00.08 0.00Hz 0.01Hz
×
F05.20 Hopping frequency range 0.00 - 30.00Hz 0.00Hz 0.01Hz
×
F06: Multistage Speed Function
F06.00
Multiple frequency
instruction 1
F00.09 - F00.08 5.00Hz 0.01Hz
○
F06.01
Multiple frequency
instruction 2
F00.09 - F00.08 5.00Hz 0.01Hz
○
F06.02
Multiple frequency
instruction 3
F00.09 - F00.08 5.00Hz 0.01Hz
○
F06.03
Multiple frequency
instruction 4
F00.09 - F00.08 5.00Hz 0.01Hz
○
F06.04
Multiple frequency
instruction 5
F00.09 - F00.08 5.00Hz 0.01Hz
○
F06.05
Multiple frequency
instruction 6
F00.09 - F00.08 5.00Hz 0.01Hz
○
F06.06
Multiple frequency
instruction 7
F00.09 - F00.08 5.00Hz 0.01Hz
○
F08: Motor Parameter
F08.00 Motor rated power 0.2 - 5.5kW
Type
confirmed
0.1kW
×
F08.01 Motor rated voltage 0 - 999V 1V
×
F08.02 Motor rated current 0.01 - 99.99A 0.01A
×
F08.03 Motor rated frequency 1.0 - 400.0Hz 50.0Hz 0.1Hz
×
F08.04 Motor rated RPM 1 - 24000rpm
Type
confirmed
1rpm
×
F08.06
Motor parameters self-
tuning
0: No action
1: Motor static self-tuning
2: Motor rotation self-tuning
3: Motor stator resistance measurement
0 1
×
F08.07 Motor stator resistance 0.00 - 99.99Ω 0.01Ω
×
