hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09-S Series User Manual V1.1 - 93 -
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F08.08 Motor rotor resistance 0.00 - 99.99Ω
Type
confirmed
0.01Ω
×
F08.09 Motor leakage inductance 0.0 - 5000.0mH 0.1mH
×
F08.10 Mutual inductance motor 0.0 - 5000.0mH 0.1mH
×
F08.11
Motor no-load excitation
current
0.00 - 99.99A 0.01A
×
F08.12
Motor core saturation
factor 1
0.00 - 1.00 1.00 0.01
×
F08.13
Motor core saturation
factor 2
0.00 - 1.00 1.00 0.01
×
F08.14
Motor core saturation
factor 3
0.00 - 1.00 1.00 0.01
×
F08.15
Motor core saturation
factor 4
0.00 - 1.00 1.00 0.01
×
F08.16
Motor core saturation
factor 5
0.00 - 1.00 1.00 0.01
×
F09: V/f Controlling Parameter
F09.00 Motor V/f curve setting
0: Straight line
1: Square curve
2: 1.2 power curve
3: 1.7 power curve
4: User-defined curve
0 1
×
F09.01
Motor V/f frequency values
F3
F09.03 - 100.0% (F08.03) 80.0% 0.1%
×
F09.02
Motor V/f voltage values
V3
F09.04 - 100.0% (F08.01) 80.0% 0.1%
×
F09.03
Motor V/f frequency values
F2
F09.05 - F09.01 (F08.03) 50.0% 0.1%
×
F09.04
Motor V/f voltage values
V2
F09.06 - F09.02 (F08.01) 50.0% 0.1%
×
F09.05
Motor V/f frequency values
F1
0.0% - F09.03 (F08.03) 0.0% 0.1%
×
F09.06
Motor V/f voltage values
V1
0.0% - F09.04 (F08.01) 0.0% 0.1%
×
F09.07 The motor torque incrase 0.0 - 30.0% 2.0% 0.1%
○
F09.08
Cut-off points of motor
torque increase manually
0.0 - 50.0% (F08.03) 30.0% 0.1%
○
F09.09
Motor slip compensation
gain
0.0 - 300.0% 0.0% 0.1%
○
