Table 9-10 Technical specifications of the clock bridging cable
Item Specification
Cable Single Cable, 120 ohm To 75 ohm Clock Cable, 30 m, MP8-II,
120CC4P0.4P430U(S)+4*SYV75-2/0.34(S)
Connector X1
type
Network Interface Connector,8-Bit 8PIN, Crystal Model Connector
120-ohm cable
type
Twisted-Pair Cable, 120 ohm, SEYVP, 0.4 mm(0.02 in.), 26AWG, 4Pairs,
Pantone 430U
75-ohm cable
type
Coaxial Cable, SYV-75-2-2(4.0Z)-1/0.34 mm, OD3.9 mm(0.15 in.),
Double-Layer Copper Braid Shielded
Cable length 30 m(98.42 ft.)
9.4 Service Cables
The service cables include Ethernet cables, 75-ohm 16 x E1 cables, and 120-ohm 16 x E1 cables.
9.4.1 Ethernet Cables
On the ATN 950B, Ethernet cables are used to input and output Ethernet service signals.
Ethernet cables are also referred to as network cables and can be classified into straight-through
cables and crossover cables according to the connection sequence of the copper cores in the
cables.
A network cable with a shield layer is a shielded cable and that without a shield layer is a non-
shielded cable.
The Ethernet service interfaces on the equipment are adaptive to the straight-through cables and
crossover cables. Hence, you can connect either type of the network cables to the Ethernet service
interfaces as required.
Ethernet cables need to be made on site.
Structure
Figure 9-10 shows the appearance of the network cable.
ATN 950B Multi-service Access Equipment
Hardware Description 9 Cables
