CAUTION
Do not change the default setting of the DIP switch. Otherwise, the EPS30-4815AF is affected.
The DIP switch indicates eight bits in binary format (on: 1; off: 0). The default value of the eight
bits is 00000100. The functions of the eight bits are as follows:
l The first five bits indicate the local and remote power addresses. Bit 5 is the highest bit and
bit 1 is the lowest bit.
l Bit 6 sets the baud rate of communication between the monitoring module and equipment.
When bit 6 is 1, the baud rate is 9600 bit/s; when bit 6 is 0, the baud rate is 19200 bit/s.
l Bits 7 and 8 are reserved.
2.3.3 Technical Specifications
The technical specifications of the EPS30-4815AF cover the input/output voltage, current,
dimensions, weight, and power consumption.
Table 2-9 lists the technical specifications of the EPS30-4815AF.
Table 2-9 Technical specifications of the EPS30-4815AF
Item
Specification
AC input Rated input voltage 220 (90 to 280) V AC
Maximum input
current
10 A
Frequency 50/60 Hz
Battery input Rated input voltage 48 V
Capacity 40 Ah
Number of
batteries
4
DC output Rated output
voltage
-53.5 V DC
Output current LOAD1: 10 A (determined by the fuse)
LOAD 2: 20 A (determined by the fuse)
Dimensions of the EPS30-4815AF
(mounting ears included)
43.6 mm (H) x 482.6 mm (W) x 270 mm (D)
Weight of the EPS30-4815AF < 10 kg
Dimensions of a battery 170 mm (H) x 197 mm (W) x 165 mm (D)
