Item Specification
Working
waveleng
th range
(nm)
770 to
860
1270 to
1360
1260 to
1360
1500 to
1580
Tx: 1260
to 1360
Rx: 1480
to 1500
Tx: 1480
to 1500
Rx: 1260
to 1360
Tx: 1260
to 1360
Rx: 1480
to 1500
Tx: 1480
to 1500
Rx: 1260
to 1360
Mean
launched
optical
power
(dBm)
-9.5 to 0 -11 to -3 -5 to 0 -2 to 5 -9 to -3 -9 to -3 -3 to 5 -3 to 5
Receiver
sensitivit
y (dBm)
-17 -19 -23 -23 –19.5 –19.5 –23 –23
Minimum
overload
(dBm)
0 -3 -3 -3 –3 –3 –3 –3
Minimum
extinction
ratio (dB)
9 9 9 9 6 6 6 6
Optical
module
code
34060286 34060473 S4016954 34060360 34060470 34060475 34060539 34060540
NOTE
For details of the optical module, see 7.2 Optical Module Labels.
Table 5-16 Performance specifications of the FE optical interface
Item
Specification
Optical interface
type
Two-fiber bidirectional interface
100BASE-FX
(15 km)
100BASE-FX
(40 km)
100BASE-FX
(80 km)
Fiber type Single-mode Single-mode Single-mode
Working wavelength
range (nm)
1261 to 1360 1263 to 1360 1480 to 1580
Mean launched
optical power (dBm)
-15 to -8 -5 to 0 -5 to 0
Receiver sensitivity
(dBm)
-28 -34 -34
Minimum overload
(dBm)
-8 -10 -10
