Table 4-36 Attributes of the 155-Mbit/s SFP optical module
Attribute Description
Transmission
distance
2 km ( 1.24 mi. ) 15 km ( 9.32
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center
wavelength
1310 nm 1310 nm 1310 nm 1550 nm
Minimum
transmit
optical power
-19.0 dBm -15.0 dBm -5.0 dBm -5.0 dBm
Maximum
transmit
optical power
-14.0 dBm -8.0 dBm 0 dBm 0 dBm
Receiver
sensitivity
-30.0 dBm -31.0 dBm -37.0 dBm -37.0 dBm
Overload
optical power
-14.0 dBm -8.0 dBm -10.0 dBm -10.0 dBm
Fiber mode Multi-mode Single-mode Single-mode Single-mode
Technical Specifications
Table 4-37 lists the technical specifications of the 4-Port Channelized STM-1c POS-SFP
Physical Interface Card(PIC).
Table 4-37 Technical specifications of the 4-Port Channelized STM-1c POS-SFP Physical
Interface Card(PIC)
Item Description
Silkscreen print 4xSTM1-cPOS
Typical power
consumption
14.5 W
Heat dissipation 47 BTU/hour
Weight 0.69 kg ( 1.52 lb )
Dimensions (W x D x H) 194 mm x 226 mm x 20 mm ( 7.64 in. x 8.90 in. x 0.79 in. )
Connector type SFP
Earliest software version V800R005C01
