Figure 4-45 Installing the oating nuts
(1) Floating nuts
The VCN510 is compact and lightweight. It can be directly xed on the cabinet with M6 screws
and mounting ears without using a guide rail. If a guide rail has been installed in the cabinet,
you are advised to remove the guide rail rst and then install the device in the cabinet. The
VCN510 is equipped with right-to-left
airow, so installing a guide rail may aect the heat
dissipation and lower the device performance accordingly.
Step 3 Install mounting ears. Take six mounting ear screw (M4 x 6 countersunk screws,
white). Use three screws to
congure one mounting ear on the left of the front
panel and the same way to congure the other ones on the right side. Then use a
Phillips screwdriver to fasten the screws to
x the mounting ears.
Figure 4-46 Installing mounting ears
Step 4 Install the device. Carry the device to be cabinet. Ensure that the mounting ears at
both sides of the device are tightly attached to the mounting bar in front of the
cabinet. Use one hand to hold the device. Use the other hand to thread M6 screws
(prepared by customers) through the slotted hole on the mounting ear. Use a
Phillips screwdriver to
x the M6 screws on the mounting ears. Each mounting ear
uses two M6 screws.
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 4 Installation Guide
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 88
