3.6.2 Removing a Server and Adjustable Guide Rail
Step 1 Wear an ESD wrist strap or ESD gloves. For details, see 1 Safety Instructions.
Step 2 Power off the server. For details, see 4 Powering On and Off the Server.
Step 3 Disconnect all power cables and signal cables from the server.
NOTE
Remove power cables first to prevent damage or injury caused by static electricity.
Step 4 Remove the server.
1. Loosen the captive screws on the server panel using a screwdriver. See (1) in Figure
3-29.
Figure 3-29 Removing the server
2. Pull out the server along the guide rails away from the cabinet. See (2) in
Figure 3-29.
3. Place the removed server on an ESD platform.
Step 5 Loosen the four screws on the guide rail. See (1) in Figure 3-30.
Step 6 Shorten the guide rail and take it out. See (2) in Figure 3-30.
RH2288 V3 Server
User Guide
3 Installing and Removing the Server
Issue 32 (2019-03-28) Copyright © Huawei Technologies Co., Ltd. 92
