RMS-SNMP01A SNMP Card
User Manual
Copyright © Huawei Technologies Co., Ltd.
Works with RCCMD, a client shutdown software developed by Generex, to
automatically and safely shut down the client that is installed with the RCCMD, thereby
protecting customers' data and preventing loss.
Alarm information is sent to the specified user mailbox at the specified time.
Change the preset password in your first login to the SNMP card. For details of WebUI, see section 4.6.2
User Mgmt. Page. For details of SSH, see section 13.2 Changing an Authentication Password.
2.2 Port Description
Figure 2-1 shows the ports on the SNMP card.
Figure 2-1 Ports
(1) Port for southbound device
(2) USB port (GSM modem supported)
(3) RS485 southbound interface
The NETWORK port of SNMP card is an RJ45 port. It communicates with the 10 Mbps/100
Mbps Ethernet over a standard network cable. The indicators show the communication status.
Table 2-1 describes the ports and indicators.
Table 2-1 Description of ports and indicators
Port for southbound
device
This port connects to
temperature and
humidity sensor or
external dry contact
card.
This port connects to
GSM modem.
