Huawei RMS-SNMP01A User Manual

RMS-SNMP01A SNMP Card
User Manual
2 Overview
Issue 08 (2020-01-09)
Copyright © Huawei Technologies Co., Ltd.
4
Silk Screen
Name
Indicator
Description
COM
RS485 southbound
interface
N/A
This port connects to
AI/DI module or
iBAT 2.0.
NETWORK
Ethernet port
Green indicator
Off: No network
cable is connected.
Steady on: A
network cable is
connected.
Yellow indicator
Blinking: The card
is communicating
with the network.

The NETWORK port is protected by a security mechanism.

The COM port and TEM_HUM port use Modbus protocol, without reference to the access
authentication mechanism.

The USB port connects to the GSM modem, without reference to the system management.
The SNMP card is equipped with a temperature and humidity sensor or an external dry
contact card over an RS485 bus. Table 2-2 lists the port definition.
Table 2-2 TEM_HUM port
Port
Pin No.
Signal
Port Type
J3004
1
GND
RJ11
2
N/A
3
RS485–
4
RS485+
5
N/A
6
12V_OUT
The COM port on the SNMP card is an RS485 southbound interface, connecting AI/DI
module or iBAT 2.0. Table 2-3 describes the pin definitions of the port.
Table 2-3 COM port
Port
Pin No.
Signal
Port Type
J3011
1
RS485+
RJ45
2
RS485–
3
N/A
