Huawei SUN2000 MB0 Series User Manual

LED Indicator Status Remarks Description
Blinking red
and green
alternately
Blinking slowly
(on for 1s and
o for 1s)
No communication with the
inverter:
– Remove and then insert
the Smart Dongle.
– Check whether the
inverter matches the
Smart Dongle.
– Connect the Smart
Dongle to another
inverter.
Check whether the
Smart Dongle is faulty or
the USB port of the
inverter is faulty.
----End
6.2 Creating a Plant
6.2.1 Downloading the FusionSolar App
● Method 1: Access https://solar.huawei.com using the mobile phone browser
and download the latest installation package.
Figure 6-2 Downloading the app
SUN2000-(12K-25K)-MB0 Series
User Manual 6 Power-On and Commissioning
Issue 01 (2023-04-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 72

Huawei SUN2000 MB0 Series Specifications

General

Type	String Inverter
Max Input Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Number of MPPTs	2
Max Input Current per MPPT	26 A
Rated Output Frequency	50 Hz / 60 Hz
Max Efficiency	98.6%
Operating Temperature Range	-25°C to +60°C
Protection Degree	IP65
Cooling	Natural Convection
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Cooling Method	Natural Convection
Protection Level	IP65
Model	SUN2000
Rated Output Voltage	230 V / 400 V
Humidity	0% - 100%
Communication	RS485
