Optional
Component
Model Function Remarks
6 kVA output
isolation
transformer
box
DGL-6/0.22 An output isolation
transformer box provides
an entire isolation
solution for customer
loads, which is dierent
from the output
transformer of
transformer-based UPSs.
The output transformer
box provides isolation
functions even in bypass
mode. The isolation
transformer is a 2:1:1
industrial-frequency
transformer. It converts
one 220 V output voltage
into two isolated 110 V
outputs.
The output
isolation
transformer box is
6 kVA, single-
phase. It is used
for the UPS2000-
G-6 kVA.
10 kVA
output
isolation
transformer
box
DGL-10/0.22 The output
isolation
transformer box is
10 kVA, single-
phase. It is used
for the UPS2000-
G-10 kVA.
Standard
battery pack
(7 Ah, 20
batteries)
ESS-240V12-7AhBPVBA01
ESS-240V12-7AhBPVBA02
ESS-240V12-7AhBPVBA04
Each battery pack consists
of twenty 12 V, 7 Ah VRLA
batteries connected in
series. It is a standard
conguration for the
UPS2000-G-6 kVA. A
maximum of four battery
packs are connected in
parallel.
● A 15 kVA/20
kVA UPS can
use at least two
battery
modules.
● If 15 kVA/20
kVA UPSs share
batteries,
dierent battery
cables need to
be
congured.
For details, see
the
ESS-240V12-
(9AhBPVBA04,
7AhBPVBA04)
Battery Pack
Quick Guide
.
Standard
battery pack
(9 Ah, 20
batteries)
ESS-240V12-9AhBPVBA01
ESS-240V12-9AhBPVBA02
ESS-240V12-9AhBPVBA04
Each battery pack consists
of twenty 12 V, 9 Ah VRLA
batteries connected in
series. It is a standard
conguration for the
UPS2000-G-10 kVA. A
maximum of four battery
packs are connected in
parallel.
UPS2000-G-(6 kVA-20 kVA)
User Manual 2 Quick Introduction
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 27
