Huawei UPS2000-G Series User Manual

Item Description Default
Value
Value Range
Frequency
range
Bypass frequency range.
When the dierence
between the bypass
input frequency and the
rated frequency is
greater than this value,
the system determines
that the bypass
frequency is abnormal
and that the bypass is
unavailable.
The Frequency range
parameter is associated
with the ECO frequency
range and must be
greater than the current
ECO frequency range.
This parameter is
congurable only after
the inverter is shut
down.
±2 Hz
±0.5 Hz, ±1 Hz, ±2 Hz,
±3 Hz, ±4 Hz, ±5 Hz,
±6 Hz
● ECO screen
Figure 4-31 ECO screen
NO TE
You can use the ECO function only if power grid conditions are good and the voltage
and frequency uctuation is within the specied ECO voltage and frequency range.
UPS2000-G-(6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 73

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
