Huawei UPS2000-G Series User Manual

Item Description Default
Value
Value Range
Voltage Set the battery equalized
voltage. The parameter is
congurable in any mode.
2.35 V/cell 2.33–2.40 V/cell
Max. time Set the maximum equalized
charge time. The parameter
is congurable in any mode.
960 min 600–999 min
Figure 4-38 Equalized Charge screen (UPS2000-G-6KRTS/UPS2000-
G-10KRTS/UPS2000-G-15KRTL/UPS2000-G-20KRTL)
Table 4-28 Equalized Charge screen (UPS2000-G-6KRTS/UPS2000-
G-10KRTS/UPS2000-G-15KRTL/UPS2000-G-20KRTL)
Item
Description Default Value Value Range
Equalized
charging
Determine whether to
enable equalized charging.
The parameter is
congurable in any mode.
Enabled Disabled,
Enabled
Time
interval
Set the interval for
equalized charging. The
parameter is congurable in
any mode.
60 days 30–180 days
Voltage Set the battery equalized
voltage. The parameter is
congurable in any mode.
2.35 V/cell 2.33–2.40 V/
cell
Max.
current
Set the maximum equalized
current. The parameter is
congurable in any mode.
2.0 A Standard
model: 1.0–2.0
A
Long backup
time model:
1.0–4.0 A
Max. time Set the maximum equalized
charge time. The parameter
is congurable in any mode.
960 min 600–999 min
● Float Charge screen
UPS2000-G-(6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 83

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
