Huawei UPS2000-G Series User Manual

Figure 4-39 Float Charge screen
Table 4-29 Float Charge screen
Item Description Default Value Value Range
Voltage Set the battery oat
voltage. The parameter is
congurable in any mode.
2.25 V/cell 2.25–2.30 V/
cell
Temp.
comp.
coef.
Set a oat voltage
correction coecient based
on the battery temperature
when a battery temperature
sensor is connected. The
parameter is
congurable in
any mode.
3.3 mV/(°C x
cell)
0.0–6.0
mV/(°C x cell)
● Discharge screen
Figure 4-40 Discharge screen (UPS2000-G-15KRTL-01/UPS2000-
G-20KRTL-01)
UPS2000-G-(6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 84

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
