Pub. 42004-550A
Elemec3 Console Manual—Version 3.0 Page 81 of 114
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-550A.docx
09/20
Playback—the playback behavior:
• Play Once—plays the message one time.
• Repeat—plays the message the number of times specified by play count.
• Continuous—plays the message until the event is cancelled.
Edit Message—open the MESSAGE BUILDER screen to enable modifying the message fragments of the
message (see the Message Builder section).
Playback required before cancel ?—event cannot be cancelled until the message has broadcasted the
specified number of times. The event is cancellable at any time if not selected.
Live Speech Event Options
Figure 85. Live Speech Event Options
Source Specific ?—use to source audio for an event via an input contact on an I/O card. Select the
SOURCE from the drop-down list for when the event triggers from an input that does not provide its own
audio.
Pre-Tone—pre-announcement tone for the live audio broadcast. These tones are accessible through the
PLAYBACK AUDIO, SYSTEM TONES screen (see the System Tones section).
Post-Tone—post-announcement tone for the live audio broadcast. These tones are accessible through the
PLAYBACK AUDIO, SYSTEM TONES screen (see the System Tones section).
Record/Playback Event Options
Figure 86. Record/Playback Event Options
Source Specific ?—use to source audio for an event via an input contact on an I/O card. Use this setting
whenever an input source doesn’t have its own push to talk (PTT) capability.
Select the SOURCE from the drop-down for when this event is triggers from an input that does not
provide its own audio. AUX #2 requires a source specific input because it does not have a push to talk
(PTT) button so an input contact enables the AUX #2 audio source. Select source specific for all
external audio sources other than AUX #1.
