O.19Part. N. 8000 H0368 (09-2008)
“KIT” ASSEMBLING INSTRUCTIONS
Reassemble: clutch disc housing (3), grooved washer (4), hub (5), lock washer
(6) and fastening nut (7) (27 mm socket and tool "A" code no. 8000 79015;
tighten at 75 Nm-7,5 kgm-55 ft/lb). Remember to bend locking tab over nut when
tight.
Reassemble clutch discs (8), clutch control cap (9), pressure plate (10) and springs
(11).
Tight the clutch springs screws (12) whilst following a cross-over pattern and in steps
(5 mm allen wrench: 8 Nm-0,8 Kgm- 5.8 ft/lb).
