S.5Part. N. 8000 H0368 (09-2008)
FUEL INJECTION SYSTEM
Fuel pump check
Remove the pump as shown on page S.2.
- A: reserve sensor
Check that in the reserve sensor has not remained any gasoline therefore set
the meter on "Impedance" position and effect the reading on the cables BLUE
and WHITE. The value will have to be: 1.3 KOhms (+/- 10%) to 20°C.
- B: pump working
Connect the RED (+) and BLACK (-) cables to a 12V stabilized feeler then
check that the fuel pump runs.
Don’t continuously effect this last check for more than 3 seconds.
