X.3Part. N. 8000 H0368 (09-2008)
TORQUE WRENCH SETTINGS
TIGHTENING TORQUES (+/- 5%)
CHASSIS
Application
Rear frame lower fastening screw M8x1,25 25,5 Nm 2,6 Kgm 18.8 ft/lb
Engine guard fastening screw M6x1 14,7 Nm 1,5 Kgm 10.8 ft/lb
Rear chain roller fastening screw M8x1,25 26,95 Nm 2,75 Kgm 19.9 ft/lb
Side stand fastening screw M8x1,25 (+LOCTITE 243) 11,75 Nm 1,2 Kgm 8.7 ft/lb
Rear frame upper fastening screw M8x1,25 25,5 Nm 2,6 Kgm 18.8 ft/lb
Frame to engine plate fastening screw M8x1,25 (+LOCTITE 270) 35,3 Nm 3,6 Kgm 26 ft/lb
Engine lower fastening screw M8x1,25 35,3 Nm 3,6 Kgm 26 ft/lb
Clutch and front brake controls clamp fastening screw M6x1 4,9 Nm 0,5 Kgm 3.6 ft/lb
Throttle control holders fastening screw M6x1 4,9 Nm 0,5 Kgm 3.6 ft/lb
Front brake hose upper fastening screw (TE, SMR) M10x1 19 Nm 1,95 Kgm 14 ft/lb
Front brake hose upper fastening screw (TC, TXC) M10x1 24,7 Nm 2,5 Kgm 18.2 ft/lb
Rear brake control pedal fastening screw M10x1,25 (+LOCTITE 243) 41,65 Nm 4,25 Kgm 30.7 ft/lb
Rear brake pump fastening screw M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Front brake pump plate fastening screw (SMR) M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Rear brake fluid tank fastening screw M6x1 2,45 Nm 0,25 Kgm 1.8 ft/lb
Rear stop control switch (TE, SMR) M10x1 19 Nm 1,95 Kgm 14 ft/lb
Front control switch connector fastening screw (SMR) M2x0,4 0,8 Nm 0,1 Kgm 0,6 ft/lb
Rear brake pedal adjusting cam fastening screw M6x1 14,7 Nm 1,4 Kgm 10.8 ft/lb
Front brake hose guide plate fastening screw M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front brake tank cap fastening screw (SMR) M6x1 4,9 Nm 0,5 Kgm 3.6 ft/lb
Front fork legs fastening screw M8x1,25 25 Nm 2,5 Kgm 18.4 ft/lb
Front wheel axle fastening screw M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Steering bearings adjusting ring nut M25x1 3,45 Nm 0,35 Kgm 2.5 ft/lb
Steering pivot fastening nut M24x1 83,3 Nm 8,5 Kgm 61.4 ft/lb
Handlebar upper clamp M8x1,25 28,4 Nm 2,9 Kgm 20.9 ft/lb
Handlebar holder fastening screw M10x1,5 21,1 Nm 2,15 Kgm 15.6 ft/lb
Front fork legs guard fastening screw M5x0,8 7,85 Nm 0,8 Kgm 5.8 ft/lb
Front fork legs ring guard fastening screw M5x0,8 2,45 Nm 0,25 Kgm 1.8 ft/lb
Rear swing arm axle fastening nut M16x1,5 (+LOCTITE 243) 122,5 Nm 12,5 Kgm 90.3 ft/lb
Rear swing arm to rocker arm fastening nut M12x1,25 80 Nm 8,2 Kgm 59 ft/lb
Tie rod to rocker arm fastening nut M12x1,25 80 Nm 8,2 Kgm 59 ft/lb
NOTE: If not otherwise specified, standard tightening torques for the following thread M5x0,8 5,6÷6,2 Nm 0,57÷0,63 Kgm 4.1÷4.5 ft/lb
M6x1 7,6÷8,4 Nm 0,80÷0,85 Kgm 5.8÷6.1 ft/lb
M8x1,25 24÷26 Nm 2,4÷2,6 Kgm 17.3÷18.8 ft/lb
