Husqvarna 2009 TE 310 - Page 394

X.4 Part. N. 8000 H0368 (09-2008)
TORQUE WRENCH SETTINGS
TIGHTENING TORQUES (+/- 5%)
CHASSIS
Application
Frame to tie rod fastening nut M12x1,25 80 Nm 8,2 Kgm 59 ft/lb
Rocker arm to tie rod lubricator M6x1 2,95 Nm 0,3 Kgm 2,2 ft/lb
Rear shock absorber to frame fastening pivot M10x1,25 52,4 Nm 5,35 Kgm 38,6 ft/lb
Rocker arm to frame fastening pivot M10x1,25 52,4 Nm 5,35 Kgm 38,6 ft/lb
Chain guide to rear swing arm fastening screw (TE-SMR) M8x1,25 25 Nm 2,5 Kgm 18.4 ft/lb
Chain guide to rear swing arm front fastening screw (TC) M8x1,25 (+LOCTITE 243)\ 10,4 Nm 1,05 Kgm 7.7 ft/lb
Chain guide to rear swing arm rear fastening screw (TC) M6x1 (+LOCTITE 243) 10,4 Nm 1,05 Kgm 7.7 ft/lb
Bracket to chain guide fastening screw (TE-SMR) M6x1 (+LOCTITE 243) 2 Nm 0,2 Kgm 1.5 ft/lb
Chain slider and rear brake hose clamp lower fastening screw M5x0,8 4,4 Nm 0,45 Kgm 3.2 ft/lb
Chain slider and rear brake hose clamp reear fastening screw (TC-TXC) M5x0,8 4,4 Nm 0,45 Kgm 3.2 ft/lb
Chain guard fastening screw (TE-SMR) M5x0,8 4,4 Nm 0,45 Kgm 3.2 ft/lb
Chain adjuster fastening nut M8x1,25 4,4 Nm 0,45 Kgm 3.2 ft/lb
Spoiler to fuel tank fastening screw M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front number holder upper fastening screw (TC-TXC) M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front number holder lower fastening screw (TC-TXC) M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Rear shock absorber guard fastening screw M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Rear fender front fastening screw M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Rear fender rear fastening screw M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front fender fastening screw M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Radiator guard fastening screw M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Side panel fastening screw M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
License plate fastening screw M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Rear reflector fastening nut M4x0,7 1,9 Nm 0,2 Kgm 1.4 ft/lb
Brake hose ring to front fairing fastening screw ø 3,5 1,9 Nm 0,2 Kgm 1.4 ft/lb
Turn signals fastening screw M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front headlamp fastening screw ø 3,9 1,45 Nm 0,15 Kgm 1 ft/lb
Electric start remote control switch cables fastening screw M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Fuel tank front rubber pad fastening screw M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Fuel cock fastening screw ø5,5 2,45 Nm 0,25 Kgm 1.8 ft/lb
Fuel tank rear fastening screw M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Air filter box front fastening screw M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
