TORQUE WRENCH SETTINGS
TIGHTENING TORQUES (+/- 5%)
CHASSIS
Application
Air filter box flange fastening nut M5x0,8 3,45 Nm 0,35 Kgm 2.5 ft/lb
Front brake caliper fastening screw (TE- TC) M8x1,25 25,5 Nm 2,6 Kgm 18.8 ft/lb
Brake hoses lower fastening screw M10x1 19 Nm 1,95 Kgm 14 ft/lb
Front wheel axle fastening screw (SMR) M10x1,5 51,45 Nm 5,25 Kgm 38 ft/lb
Front brake caliper fastening screw (SMR) M10x1,5 25,5 Nm 2,6 Kgm 18.8 ft/lb
Brake caliper holding plate to front fork (SMR) M10x1,5 25,5 Nm 2,6 Kgm 18.8 ft/lb
Front wheel axle fastening screw (TE-TC-TXC) M20x1,5 51,45 Nm 5,25 Kgm 38 ft/lb
Front brake disc fastening screw (TE-TC-TXC) M6x1 (LOCTITE 243) 14,7 Nm 1,5 Kgm 1 0.8 ft/lb
Front brake disc fastening screw (SMR) M8x1,25 34,7 Nm 3,54 Kgm 25.6 ft/lb
Rear brake disc fastening screw M6x1 (LOCTITE 243) 14,7 Nm 1,5 Kgm 10.8 ft/lb
Front wheel nipple M4,07x0,75 4,4 Nm 0,45 Kgm 3.2 ft/lb
Rear wheel nipple M4,5x0,75 4,4 Nm 0,45 Kgm 3.2 ft/lb
Rear wheel sprocket fastening nut M8x1,25 (+LOCTITE 243) 34,3 Nm 3,5 Kgm 25.3 ft/lb
Rear wheel axle fastening nut M20x1,5 142,1 Nm 14,5 Kgm 104.8 ft/lb
Drive sprocket cover fastening screw M6x1 10,4 Nm 1 Kgm 7.7 ft/lb
Exhaust silencer fastening screw M6x1 10,4 Nm 1 Kgm 7.7 ft/lb
Exhaust pipes to cylinder head fastening screw M6x1 10,4 Nm 1 Kgm 7.7 ft/lb
Instrument fastening screw ø4,8 3,45 Nm 0,35 Kgm 2.5 ft/lb
Radiator fastening screw M6x1 7 Nm 0,72 Kgm 5.2 ft/lb
