32 Excelon Operator’s Manual
Operation
① Plug the Power Cable into the receptacle at the back of the product and turn on
the power.
② Insert the Lens Adapter into the Lens Adapter Setter (Pay attention on the
direction).
③ Place the marked Lens over the Lens Holder.
④ According to the Lens Type (Bi-Focal, Progressive) and Blocking Type (Optical
Center, Box Center), adjust the marking point using the scale plate.
⑤ Turn the Switch Lever to place the Lens Adapter Setter over the Lens and press it
to complete the blocking job.
• Push down the switch lever as possible as the scale plate is close to the lens. If
then, the operator can minimize the error of the optical illusion.
• Do not force too much on the Switch Lever for blocking. Otherwise, it may
scratch or damage the Lens.
