104
4. System Setup
( A ) Feed to turret speed setting
Select 1.< Feed to turret speed setting >
Fast speed setting for pushrod to reach 20mm bar
stock.
speed setting ranges:
1000- 10000 (100 -1000mm/sec)
Factory setting data : 5000 (500mm/sec)
Slow speed setting for push bar to require position
speed setting ranges:
300- 5000 (30 -500mm/sec)
Factory setting data : 800 (80mm/sec)
To Next Page
