Hydrafeed MSV 65 - Page 150

147
8. Warning List
Warning
No.
Warning Picture Cause Action
19
No material!!
Bar feeder checked the
bar inside of spindle,
but it is No material.
(when you select chuck
close bar check)
-Touch on <NEXT>.
-Turn the switch manual
mode.
-Go to reference point.
CNC chuck open
-Again turn the switch auto
mode.
-And start automatic
working.
20
L (MAX) setting too long.
Bar length(MAX setting)
( on 3.11.5), L(MAX)
setting more than the
bar rack’s length.
Refer ( on 3.11.5) L(MAX)
setting range.
21
Multiple fed
components, you can
not select eject remnant
by new bar.
Select eject remnant by
pushrod (on 3.11.2).
