Hydrafeed MSV 65 - Page 99

96
4. System Setup
Pxx (Sub program)
( 1 ) Chuck open
( 2 ) M00(CNC waiting)
( 7 ) Chuck close
( 8 ) W – 100
(turret come to loading position)
( 9 ) Chuck open
(10 ) M00(CNC waiting)
Chuck close
Part off
M99(go to main program)
Note :
Clamping of collet chuck without material
may cause the damage of the chuck.
Three jaw chuck will be exceptional.
