Hypertherm XPR170 - Bevel Cutting

Operation
6
218 810060 Instruction Manual XPR170
It is possible, however, to cut other types of stainless steel and aluminum.
Non-ferrous process availability is based on the type of gas connect console that you have (Core,
VWI, or OptiMix).
Table 28 – Available non-ferrous processes by gas connect console type and gas type.
Table 29 – Process recommendations for cut quality, based on metal thickness and type
Gas connect console Available stainless steel processes Available aluminum processes
Core N
2
/N
2
N
2
/N
2
, Air/Air
VWI N
2
/N
2
, N
2
/H
2
O, F5/N
2
N
2
/N
2
, N
2
/H
2
O, Air/Air
OptiMix N
2
/N
2
, N
2
/H
2
O, H
2
-mix/N
2
, F5/N
2
N
2
/N
2
, N
2
/H
2
O, H
2
-mix/N
2
, Air/Air
Metal thickness Metal type
Metric (mm) English (in) Stainless steel Aluminum
10.036
40 A N
2
/N
2
40 A Air/Air
30.105
3.5 0.125
60 A N
2
/N
2
60 A Air/Air
50.188 60A N
2
/N
2
60.250
80 A F5/N
2
80 A N
2
/H
2
O
10 0.375
12 0.500 130 A H
2
-mix/N
2
130 A N
2
/H
2
O
16 0.625
170 A H
2
-mix/N
2
170 A N
2
/H
2
O
20 0.750
25 1.000
38 1.500
