Hypertherm XPR170 User Manual

XPR300 Instruction Manual 809480 73
Installation
Before you begin
Before you begin installation, make sure to:
 Read, understand, and follow all of the safety instructions that are in this manual, the Safety
and Compliance Manual (80669C), the Radio Frequency Warning Manual (80945C),
and
a
ffixed to the cutting system. Failure to follow safety instructions can result in personal inju
ry
or equipment damage.
 Get all necessary reference documents. Refer to Document requirements on page 39.
 Consider the following requirements about where to position system components:
 Site requirements on page 60
 Length requirements for hoses, cables, and leads on page 60
 Bend radius requirements for hoses, cables, and leads on page 61
 Distance requirements between high-frequency leads and control cables on page 62
 Distance requirements for ventilation and access on page 62
 Distance requirements for communications on page 63
 Review the Installation checklist on page 74.
This plasma system can make more than the permitted acoustical noise levels as defined by national
and local codes. Always put on correct ear protection when cutting or gouging. Any acoustical
noise measurements taken are related to the specific environment in which the system is used.
Refer to Noise can damage hearing in the Safety and Compliance Manual (80669C).
In addition, you can find an Acoustical Noise Data Sheet for your system at
www.hypertherm.com/docs. In the search box, enter data sheet.

Hypertherm XPR170 Specifications

General

Brand	Hypertherm
Model	XPR170
Category	Welding System
Language	English
