Diagnostics and Troubleshooting
8
358 809480 Instruction Manual XPR300
Gas connect console high frequency PCB (141354)
Torch connect console ohmic PCB
(141368)
LED Signal
D1 HIGH FREQUENCY ENABLE
LED Signal
D2 Ohmic contact
