Parts List

XPR300 Instruction Manual 809480 365

5 127344 Coolant filter housing 1

027005 Coolant filter (fine) 1

6 229777 Coolant hose (1 inch) 1

7 428729

Coolant pump and motor assembly:

Adapter: 1-5/8 inch X 1 inch NPT X #16 JIC

Plug with O-ring

Coolant pump screen (coarse)

Pump and motor

Adapter: 1 inch MNPT X 1 inch MNPT hexagonal collar

Adapter: 1 inch MNPT X 3/8 inch FNPT X 1/4 inch FNPT

Adapter: 3/8 inch hexagonal

Coolant solenoid valve assembly

8 006132 Coolant bypass check valve 1

9 229721 Coolant solenoid valve assembly 1

10 229654 Thermistor: Copper pipe clip with electrical connector 1

11 127559 Coolant pump screen (coarse) 1

12 229843 Plug and O-ring 1

13 002561 Coolant reservoir 1

14 006113 Coolant check valve 1

428330 Kit: Tubing (1 inch hose not included) 1
