2.5 Installation of rod type
2-32
2. Installation
[When using tip adapter]
T
ransported objects can
be secured using the
internal thread of the tip adapter
.
→
For precautions for mounting, refer to page 2-29.
For EC-R6 (Part model number EC-NF
A-R6)
For EC-R7 (Part model number EC-NF
A-R7)
Ty
p
e
Tightening torque
when mounting ELECYLINDER
EC-R6
30.00N
･
m
EC-R7
35.00N
･
m
163
165
