3.5 Wiring connections
(for cables)
3-14
3. Wiring
Brake release wiring
For the specification with
brake, when installing a forc
ible brake release switch,
connect the [brown] cable wire.
Power capacity of 24VDC ±10%/
200mA
or higher is require
d.
Wiring
color
Signal
abbreviation
Function overview
Required specifications
Brow
n
BKRLS
Brake release
24VDC ±10%/200mA
or higher
216
218
