7.1 Troubleshooting confirmations
7-2
7. Troubleshooting
(2) Check status indicator LED (wireless status LED)
○: Light ON
×: Light OFF
★: Blinking
Wireless status LED
(Left side as seen from
the motor side)
Wireless status
Green Red
× ×
Wireless hardware initializing
Wireless not connected (transmitting monitor data)
Connecting from wired teaching pendant
×
★
ON 200ms/
OFF 200ms
alternate blinking
Wireless hardware error
★
ON 150ms/
OFF 150ms
alternate blinking
× Connecting through wireless
GreenRed
