IAI ROBO Cylinder RCP2 Series User Manual

13
2. Motor Coupling Type (Cleanroom Specification) RCP2CR
SA5C, SA6C, SA7C
SS7C, SS8C, HS8C
Caution: The cable directly connected to the actuator is not a robot cable even when
ordered with a robot cable option. When designing, please make sure not to
give repeated bending loads to this cable.
The robot cable is applicable only to the connecting cables.
Motor End Cap
Stainless Sheet
Opposite
Motor End
Side Cover
Right Side
Left Side
Cable Joint Connector
A
ctuator Cable
Motor
End
Front Cover
Base
Bearing Housing
Slider
Motor End Cap
Motor Cover
Suction Joint
Stainless Sheet
Opposite
Motor End
Side Cover
Right Side
Left Side
Cable Joint Connector
A
ctuator Cable
Motor
End
Front Cover
Base
Bearing Housing
Slider
Motor Cover
Suction Joint
