IAI ROBO Cylinder RCP2 Series User Manual

14
3. Motor Reversing Type
ƔSA5R, SA6R
ƔSA7R
Caution: The cable directly connected to the actuator is not a robot cable even when ordered with
a robot cable option. When designing, please make sure not to give repeated bending
loads to this cable.
The robot cable is applicable only to the connecting cables.
Motor End
Pulley Cover
Stainless Sheet
Opposite
Motor End
Side Cove
r
Right Side
Left Side
Front Cove
r
Base
Mounting Flange
Motor End Cap
Motor Cove
r
Slider
Stainless Sheet
Opposite
Motor End
Side Cove
r
Right Side
Left Side
Motor End
Front Cove
r
Base
Mounting Flange
Pulley Cover
Motor End Cap
Motor Cove
r
Slider
Motor Bracket
