2. Specification
RCP2SA5R
Payload (kg)
Payload (kg)
Payload (kg)
Payload (kg)
Speed (mm/s)
Speed (mm/s)
Lead 3
Lead 6
Lead 12
Lead 3
Lead 6
Lead 12
Lead 3
Lead 6
Lead 12
Lead 3
Lead 6
Lead 12
Vertical
Horizontal
Vertical
Horizontal
Speed (mm/s)
[Controller (with “H” at the end of the model number)]
Speed (mm/s)
It is the payload when operating with the rated
acceleration below:
Lead 3
Rated acceleration : 0.2 G, when horizontal,
0.2 G when vertical
Lead 6
Rated acceleration : 0.3 G, when horizontal,
0.2 G when vertical
Lead 12
Rated acceleration : 0.3 G, when horizontal,
0.2 G when vertical
RCP2SA6R
It is the payload when operating with the rated
acceleration below:
Lead 3
Rated acceleration : 0.2 G, when horizontal,
0.2 G when vertical
Lead 6
Rated acceleration : 0.3 G, when horizontal,
0.2 G when vertical
Lead 12
Rated acceleration : 0.3 G, when horizontal,
0.2 G when vertical
