11. key (Return key)
Confirms the input data and moves the cursor position forward .
12. PAGE UP · PAGE DOWN key
Increment or decrement edit and display item No. (Position No., Program No., Step No., etc.)
13. ON/OFF key
Switches servo ON or OFF of axes. (It is valid within Teac (teach) mode area)
14. HOME key
Executes homing. (It is valid in the Teac (teach) mode area with the servo ON )
15. MOVE key
Starts actuator movement or continuous movement. (It is valid in the Teac (teach) mode area
with the servo ON.)
16. STOP key
Stops actuator movement or continuous movement. (It is valid in the Teac (teach) mode area
with the servo ON.)
17. 1 1 2 2 3 3 4 4 (Jog keys)
1 Minus direction jog movement for the 1st axis and 5th axis
1 Plus direction jog movement for the 1st axis and 5th axis
2 Minus direction jog movement for the 2nd axis and 6th axis
2 Plus direction jog movement for the 2nd axis and 6th axis
(It’s valid in the Teac (teach)
mode area with the servo
ON
3 Minus direction jog movement for the 3rd axis
3 Plus direction jog movement for the 3rd axis
4 Minus direction jog movement for the 4th axis
4 Plus direction jog movement for the 4th axis
Such jog actions with the JOG button are also valid for any not-homed axes. However,
coordinate values in this case have no meaning. Therefore, be extremely careful about
interference with the stroke end.
If jog operation is performed to the axis in action under the operation-button-acceptable
condition, the operation of the applicable axis is aborted when the JOG operation button is
turned OFF. (The next operation starts, if any.)
