14. Parameter Edit
You can change the parameters corresponding to your system.
When you change the parameters by yourself, please note the parameter contents.
Parameters will be valid by restoring the power or executing software reset after Flash ROM
writing.
Select the F1 (Edit) key on the mode selection
screen.
Select the F4 (Para) key on the edit screen.
14-1. Parameter Edit Items
Parameter items will be displayed in the function key area.
Each time by pressing the SF key, items will be shifted and displayed.
Parameter Edit Items
I/O: I/O parameter
Comn: All-axis common parameter
Axis: Each-axis parameter
Drv: Driver card parameter
Ecdr: Encoder parameter
IoSl: I/O slot card parameter
Othe: Other parameter
Select the parameter item to edit with function key.
89
To Next Page
