15-8. Error
Detail
Information
Displays the error detail information.
Select the F3 (ErrL) key on the monitor items screen.
Mode Transition:
List No.
Error Code
Error Message
Program No.
Step No.
A
xis No.
Position No.
Information 1
Information 2
Information 3
Information 4
103
105
107
