15-6. Axis
Status
Displays the current positi
on of each axis, servo stat
us, sensor status, etc.
Select the F1 (ASts) key from the monitor items screen.
Mode Transition:
Posi: Current
Position
Srvo: Servo
S
tatus
Snsr:
Sensor Input S
tatus
Ecdr: Encoder
S
tatus
ErrA:
Axis Related Error
(1) Current
position
Mode Transition:
N: Servo ON
F: Servo OFF
(2) Servo
status
Mode Transition:
Axis No. can be switched wi
th the PAGE UP · PAGE
DOWN keys.
A
xis No.
Servo ON axis in use
Homing
Servo
Moving Command Normal End
96
98
100
