15. Monitor
Monitor each status, global variable, port status, etc.
Select the F3 (Moni) key from The mode selection
screen.
15-1. Monitor Items
Monitor items will be displayed in the function key area.
Each time by pressing the SF key, items will be shifted and displayed.
Monitor Items Screen
In: Input port
Out: Output port
GFlg: Global flag
GVar: Global variable
Asts: Axis status
SSts: System status
ErrL: Error detail information
Ver: Version information
Select the item to monitor with the function key.
93
