15-9. Version
Information
Displays version information.
Select the F4 (Ver) key on
the monitor items screen.
Mode Transition:
Main: Main
Drv: Driver
TP: T
eaching
Pendant
(1) Main
Mode Transition:
Controller Main Application Version
Controller Main Core Versi
on
(2) Driver
Mode Transition:
Driver CPU V
ersion
(3) T
eaching
Pendant
Mode Transition:
Teaching Pendant Application Version
Teaching Pendant Core Version
104
106
108
