Screws
2
Electronics assembly
5. Stand at the front of the rack. With the help of another service representative,
place the back of the 2145 UPS onto the support rails and then slide it into the
rack.
6. Install the front flathead screws (
1
in Figure 88 on page 127).
1
2
Figure 87. Removing the 2145 UPS electronics assembly
126 IBM System Storage SAN Volume Controller: Hardware Installation Guide
