Adding and removing drives
The tower has six bays for various types of drives. Some
of these bays already hold drives that were installed at
the factory.
When you purchase a new drive, make sure you also
purchase the appropriate power and signal cables.
Identifying drive bays
The tower can accommodate 3.5-inch slim and 3.5-inch
half high drives, such as diskette and tape drives. The
tower can also accommodate 5.25-inch half high drives,
such as diskette, hard disk, tape, and CD-ROM drives.
Four of the bays in your tower have external access. Two
do not.
You can install a drive in any empty bay that
accommodates the drive’s size. Use the following table
to help you determine where to install a new drive.
To identify drive bays in the tower, see “Identifying the
parts of the tower” on page 78.
Bay Drive Specifications Bay Capacity
1 Can hold a 3.5-inch slim drive,
such as a diskette or tape drive.
101.6 x 25.4 mm
(4.0 x 1.0 in.)
2 Can hold up to a 5.25-inch half
high drive, such as a diskette,
hard disk, tape, or CD-ROM drive.
149 x 41.3 mm
(5.87 x 1.625 in.)
3 Can hold up to a 5.25-inch half
high drive, such as a diskette,
hard disk, tape, or CD-ROM drive.
149 x 41.3 mm
(5.87 x 1.625 in.)
4 Can hold up to a 3.5-inch half
high drive, such as a diskette or
tape drive.
101.6 x 41.3 mm
(4.0 x 1.625 in.)
5 Can hold a 3.5-inch slim hard
disk. (No external access.)
101.6 x 25.4 mm
(4.0 x 1.0 in.)
6 Can hold a 3.5-inch slim hard
disk. (No external access.)
101.6 x 25.4 mm
(4.0 x 1.0 in.)
Note: Using the appropriate installation hardware, you can
install smaller drives than those listed here.
